Technical data
From installation dimensions to connection media and scope of delivery: here you will find the most important technical specifications.
Rotoclear C Basic
Installation dimensions
Both the camera head and the control unit of the Rotoclear C Basic are designed to be compact, allowing flexible installation.
| Camera head | |
| Diameter | 70 mm |
| Length (without mount) | 50 mm |
| Variants and optics | more details |
| HDMI unit | |
| Length | 172 mm |
| Width | 82 mm (105 mm incl. clip) |
| Height | 42 mm |
CAD data
Would you like to integrate the Rotoclear C Basic into your design? On request, we will be happy to provide you with access to the corresponding CAD data.
Connection media
The Rotoclear C Basic only requires power and a little compressed air to operate. Video output is provided directly via HDMI.
| Rated voltage HDMI unit | 24 VDC, reverse polarity protection |
| Power consumption | 36 W (max., with 1 camera head and 2 signal amplifiers) |
| Current | 1.5 A (max., with 1 camera head and 2 signal amplifiers) |
| USB ports | 2 × USB 2.0, 500 mA max. each |
| Data | 1 × M12 x-coded (female) |
| Video signal | HDMI (1x) |
Configure your optimal system setup
With our practical online configurator, you can put together your individual package with exactly the components (including mounts) you need.
Rotoclear C Basic Operating Manual
Looking for all technical data or further information on configuration, installation, operation, and maintenance? You’ll find it in our operating manual.
Rotoclear C Basic Operating Manual
(PDF max. 2 MB)
German | English
Rotoclear C2
Installation dimensions
The compact design of the camera heads and control unit of the Rotoclear C2 allows installation even in tight spaces.
| Camera heads | |
| Diameter | 70 mm |
| Length (without mount) | 50 mm |
| Varianten und Optiken | more details |
| Control unit | |
| Length | 197 mm |
| Width | 104 mm (126 mm incl. clip) |
| Height | 44 mm |
CAD data
Need CAD data to integrate the Rotoclear C2 into your design? On request, we will be happy to provide you with access.
Connection media
The Rotoclear C2 requires only power and a small amount of compressed air to operate. Images are output directly via HDMI and/or network.
| Rated voltage control unit | 24 VDC, reverse polarity protection |
| Power consumption | 60 W (max., with 2 camera heads and 4 signal amplifiers) |
| Current | 2.5 A (max., with 2 camera heads and 4 signal amplifiers) |
| Ethernet | 1 × 1 Gbit/s and 1 × 100 Mbit/s |
| USB ports | 3 × USB 2.0, 500 mA max. each (1 × top left + 2 via hub) |
| Videosignal | HDMI (1x) |
| Data | 2 × M12 x-coded (female) |
Configure your optimal system setup
With our practical online configurator, you can put together your individual package with exactly the components (including mounts) you need.
Rotoclear C2 Operating Manual
Looking for all technical data or further information on configuration, installation, operation, and maintenance? You’ll find it in our operating manual.
Rotoclear C2 Operating Manual
(PDF max. 2 MB)
German | English
Rotoclear C Pro
Installation dimensions
The compact design allows installation even in tight spaces.
| Camera heads | |
| Diameter | 70 mm |
| Length (without mount) | 50 mm |
| Varianten und Optiken | mehr Details |
| Control unit | |
| Length | 205 mm |
| Width | 104 mm (125 mm incl. clip) |
| Height | 44 mm |
CAD data
Would you like to integrate the Rotoclear C Pro into your design and need the corresponding CAD data? On request, we will be happy to provide you with access.
Connection media
The Rotoclear C Pro requires only power and a small amount of compressed air to operate. Images are output directly via HDMI and/or network.
| Rated voltage control unit | 24 VDC, reverse polarity protection |
| Power consumption | 96 W (max., with 2 camera heads and 4 signal amplifiers) |
| Current | 4 A (max., with 2 camera heads and 4 signal amplifiers) |
| Ethernet | 2 × 1 Gbit/s |
| USB ports | 4 × USB 3.0, 900 mA max. each |
| DisplayPort | 1x |
| Video signal | HDMI (1x) |
| Data | 2 × M12 x-coded (female) |
Configure your optimal system setup
With our practical online configurator, you can put together your individual package with exactly the components (including mounts) you need.
Rotoclear C Pro Operating Manual
Looking for all technical data or further information on configuration, installation, operation, and maintenance? You’ll find it in our operating manual.
Rotoclear C Pro Operating Manual
(PDF max. 2 MB)
German | English
