Technical data – Rotoclear S3
Whether it’s installation dimensions, connection media, or scope of delivery – here you’ll find all the technical data for the Rotoclear S3. If you have further questions about dimensions or details, don’t hesitate to contact us directly.
Installation dimensions
The Rotoclear S3 has a thickness of 33.5 mm. However, you should allow for at least 34 mm of clearance at the inner edge of the machine window to ensure that the spinning window does not collide with the machine door when it is moved.
| Thickness | 33,5 mm |
| Clearance to inner edge of the machine window | min. 34 mm |
Connection media
The Rotoclear S3 requires a power supply for operation. The use of sealing air is optional, but we recommend it to ensure the spinning window is completely sealed.
| Power supply | 24 VDC (16–28 V) |
| Sealing air | 2- 5 mbar (measured at the connection box) |
Scope of delivery
| Included in both versions: | |
| 1 x | Rotoclear S3 – basic unit (rotor and stator) |
| 1 x | Protective hose (2m) |
| 1 x | Air hose (8 m) |
| 1 x | Power cable (10 m) |
| 1 x | Electric-pneumatic adapter (protective hose) |
| 1 x | Screw-in angle |
| 1 x | Operating manual (DE/EN) |
| 10 x | Cylinder bolts |
| Additionally in the bonding version: | |
| 1 x | Bonding flange with cover |
| 1 x | Two-component adhesive |
| 1 x | Cleaning cloth |
| 1 x | Dispensing gun for 2K adhesive |
| 1 x | Bonding instructions |
| Additionally in the screw version: | |
| 1 x | Positioning template |
| 1 x | Screw flange (clamping range 6–16 mm) |
All Rotoclear S3 technical data available
for download
You can find the complete technical specifications in our operating manual:
Rotoclear S3 Operating Manual
(PDF max. 2 MB)
German | English
